    Rotary Electrical Slip Ring 9 Circtir 10A With Fiber Optic

    Ask Lasest Price
    Brand Name : JINPAT
    Model Number : LPC-0910-3502-F001
    Certification : ISO9001.ISO14000.CE.UL.FCC.RoHS
    Price : Negotiable
    Payment Terms : T/T, C/C, Paypal
    Supply Ability : 500 units/week
    Delivery Time : 2 weeks ARO
    • Product Details
    • Company Profile

    Rotary Electrical Slip Ring 9 Circtir 10A With Fiber Optic

    Precious Metal Max 1650nm Rotary Slip Ring For Testing Equipment


    JINPAT LPC-0910-3502-FO01 is a high precision slip ring with compact design. With an integrated optical rotary joint, this slip ring model is able to transmit power, signals and optical signals. This slip ring model adopts aluminum alloy as housing material and precious metal as contact material. Taking up special construction and manufacturing technique, LPC-0910-3502-FO01 shows great anti-interference, and guarantee an extremely low data package loss. It is very smooth during rotation, and therefore produce barely any electrical noise. LPC-0910-3502-FO01 takes up advanced technique in the field, and is well-received among the customers. This capsule optical slip ring is fit for electrical devices with demand to transmit optical signals.


    Product outline drawing


    Product parameter table


    Optical fiber Parameter
    Optical fiber typeSingle modeWorking wavelength1310nm-1650nm
    Insertion Loss<2dBReturn loss>40dB
    Insertion Loss-WOW<0.5dBLight power23dBm
    The bending radius50mmConnect ModelST Flat Face
    Electronic & ElectricMechanical
    Circuits Total44 CKTWorking Speed0-100rpm
    Circuits Detail9*10A/35*2AContact MaterialPrecious Metal
    Rating Voitage240V AC/DCHousing MaterialAluminum Alloy
    Dielectric Strength≥500VAC@50HzLead Wire LengthStator:2000±5mm
    Rotor:2000±5mm
    Insulation Resistance≥100MΩ@500VDCDynamic Resistance
    Fluctuation Value
    ≤15mΩ
    EnvironmentRemarks
    Working Temperature-40℃~+85℃Application/
    Working Humidity≤60%RHOther/
    IPIP54Note:"P"stands for power,"S"stands for signal.

    The LPM micro-capsule slip ring can integrate 30 or more circuits, and the optional outer diameter is 12.5mm~16mm. This series adopts advanced military surface treatment technology, featuring high precision, compactness and easy assembly. The gold-to-gold contact ensures low resistance and long service life. Representative models: LPM 04A / 06A / 12F / 18C / 24A / 30A, etc. It can integrate various signals: Ethernet, USB, RS, LVDS, CAN bus, FireWire, SDI and HDMI, etc. In addition, various non-standard slip rings can be customized.
