Rotating Electrical IP66 Capsule Slip Ring 16 Circuits 400rpm Ethernet Rotary Joint

JINPAT LPC-36T-1603-HD01-IP66(JP35-057-01HW) is a capsule slip ring model that takes up aluminum alloy as housing material. This model has 36 channels at total, among which 16 channels are 3A power channels and 1 HDMI channel. LPC-36T-1603-HD01-IP66 adopts gold to gold contact which contribute to its great electronic performance and smooth operation during rotations. The rotating speed ranges from 0~400rmp. This slip ring model can work in low and high temperature while maintain a fine and stable operation. It can also cope with humid environment, withstands humidity below 60%RH. With protection grade up to IP66, JINPAT LPC-36T-1603-HD01-IP66 is able to transmit signal and power in a stable and reliable way even in a demanding environment.

Product outline drawing

The LPM micro-capsule slip ring can integrate 30 or more circuits, and the optional outer diameter is 12.5mm~16mm. This series adopts advanced military surface treatment technology, featuring high precision, compactness and easy assembly. The gold-to-gold contact ensures low resistance and long service life. Representative models: LPM 04A / 06A / 12F / 18C / 24A / 30A, etc. It can integrate various signals: Ethernet, USB, RS, LVDS, CAN bus, FireWire, SDI and HDMI, etc. In addition, various non-standard slip rings can be customized.

JINPAT Electronics, founded in 1996, is a national high-tech enterprise specializing in R&D, manufacturing and sales of high-precision slip rings. Typical products like Capsule Slip Ring, Through-bore Slip Ring, Large-current Slip Ring, Coax Rotary joint, Fiber Optic Slip Ring, Separate Slip Ring, Pin Slip Ring.

Besides, customization is supported to cater to the different application in that slip ring can be designed exclusively integrated with Ethernet, USB, HDMI, Sensor, CAN Bus, Thermocouple, RS232, RS422 and so forth.
