Cap Type Rotary Slip Ring 6 Circuit 2A 240 VAC/DC Low Contact Resistance

Ask Lasest Price
Brand Name :	JINPAT
Model Number :	LPC-06A
Certification :	ISO9001.ISO14000.CE.UL.FCC.RoHS
Price :	Negotiable
Payment Terms :	TT/CC/Paypal
Supply Ability :	50K units/week
Delivery Time :	2 weeks ARO

Add to Cart

Product Details
Company Profile

Cap Type Rotary Slip Ring 6 Circuit 2A 240 VAC/DC Low Contact Resistance

The LPC-06B capsule slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary part to a rotating part.

The LPC-06B unit is a standard, off-the-shelf unit that uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical connections.

LPC-06B Slip Ring parameter

Protection Grade	IP54
Working Speed	300 RPM
Circuits	6
Current Rating	2A Or higher
Voltage	240VAC
Working Temperature	-40~+80℃
Electric shock material	Gold to Gold
Wire specification	AWG28#, silver plated , UL
Lead Wire Length	Rotor:250mm; Stator:250mm
Insulation	1000MΩ@500VDC
Dielectric Strength	/
Electrical noise	/

LPC-06B Slip Ring Outline Drawing
