Precious Metal 300rp Through Hole Slip Ring Inner Diameter 38.1mm

Ask Lasest Price
Brand Name :	JINPAT
Model Number :	LPT038
Certification :	ISO9001.ISO14000.CE.UL.FCC.RoHS
Price :	Negotiable
Payment Terms :	TT/CC/Paypal
Supply Ability :	1000 units/week
Delivery Time :	2 weeks ARO

Add to Cart

Product Details
Company Profile

Precious Metal 300rp Through Hole Slip Ring Inner Diameter 38.1mm

Precious Metal 300rp Through Hole Slip Ring Inner Diameter 38.1mm

The LPT038 provides an economical, readily available solution when a compact through bore configuration is required.

This unit provides a 38.1mm through bore for routing hydraulic or pneumatic lines and a compact 86mm outside diameter for minimal space applications. The 15 amps per circuit are available in 6, 12, 18 and 24 ring configurations in 4 housing lengths.

Electronic & Electruc			Mechanical
Circuits	Total	6CKT	Working Speed	0~300rp
	Detail	6X5A	Inner Diameter	Φ38.1mm
Rating Voltage		240VAC/ DC	Contact Material	Precious Metal
Dielectric Strength		1000VAC@50Hz	Housing Material	Aluminum Alloy
Insulation Resistance		≥500MΩ@500VDC	Lead Wire Length	Stator:300mm Rotor:300mm
Environment			Remarks
Working Temperature		-20°C~+60°	Other	/
Working Humidity		≤60%RH

Outline Drawing


Outline Drawing


Outline Drawing


Outline Drawing
