    Capsule Slip Ring 12 Channels 300rpm

    Ask Lasest Price
    Brand Name : JINPAT
    Model Number : LPC-12B
    Certification : ISO9001.ISO14000.CE.UL.FCC.RoHS
    Price : Negotiable
    Payment Terms : TT/CC/Paypal
    Supply Ability : 50K units/week
    Delivery Time : 2 weeks ARO
    • Product Details
    • Company Profile

    Capsule Slip Ring 12 Channels 300rpm

    Compact Capsule Slip Ring 12 Channels Max. Speed Up to 300rpm with Copper Plated Wires


    Description

    The series of compact capsule electrical slip ring with the features of flexibility, cost-effectiveness, and reliability, and it offers a low torque design with gold-to-gold contacts. It can meet 360 degrees free rotation and has a very long life about 10 million rotary cycles.

    The LPC-12B Slip Ring which is also called a rotary electrical interface, commutator, collector, swivel or an electrical rotary joint, provides smoother running, lower torque and lower electrical noise than competitive slip rings. It is available in 6, 12 circuit modes.


    Specifications
    Operating Speed0-300 rpm
    Number of Circuits12
    Voltage240 VAC/DC
    Current Rating2 amps per circuit
    Temperature Range-20℃ to +60℃
    Contact MaterialGold to Gold
    Lead Size28# silver plated copper
    Lead LengthStandard 250 mm (9.843inch)
    Dielectric Strength≥500 VAC @50Hz, between each circuit
    Insulation Resistance100 MΩ @ 500 VDC
    Electronic Noise1mΩ Min

    Outline Drawing


    Application Picture
