3-Channel RF Rotary Joint with 60RPM Rotating Speed & Frequency Up To 3 GHz for Remotely Operated Vehicles

Description

A slip ring is also called a rotary electrical interface, collector, swivel or rotary joint. A slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transmitting power and/or data from a stationary part to a rotating part. A slip ring can improve system performance by simplifying operations and eliminating damage-prone wires wrapping from moving joints.

The LPHF Series features precious metal contacts at the rotary interface. Fiber brush technology offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates. In addition, fiber brushes do not require lubrication and produce virtually no wear.It is specially designed for high-frequency signal transmission, with frequency up to 50GHz.

Flying lead wires on the rotating side and solder terminals on the stator side complete the electrical connections. Precision ball bearings and the patented fiber brush design allow operation up to 10,000 rpm without the cooling equipment.

Specifications

Outline Drawing

Application picture ( Remotely Operated Vehicles)

JINPAT Electronics, founded in 1996, is a national high-tech enterprise specializing in R&D, manufacturing and sales of high-precision slip rings. Typical products like Capsule Slip Ring, Through-bore Slip Ring, Large-current Slip Ring, Coax Rotary joint, Fiber Optic Slip Ring, Separate Slip Ring, Pin Slip Ring.

Besides, customization is supported to cater to the different application in that slip ring can be designed exclusively integrated with Ethernet, USB, HDMI, Sensor, CAN Bus, Thermocouple, RS232, RS422 and so forth.
